Display incoming references directly in a document's form, without storing the data as part of the document.
Studio's inline incoming references feature allows you to define a component that will display any incoming references to the current document.
Unlike a field containing an array of references, these incoming references are not part of the document and will display automatically when new references are made.
Prerequisites:
To add incoming references to a field in your schema, import and use the defineIncomingReferenceDecoration helper.
import {defineType} from 'sanity'
import {defineIncomingReferenceField} from 'sanity/structure'
export default defineType({
name: 'author',
type: 'document',
renderMembers: (members) => {
return [
...members, // Places the decoration after all existing fields.
defineIncomingReferenceDecoration({
name: 'incomingReferences',
title: 'Incoming references',
types: [{type: 'author'}],
}),
]
},
fields: [],
})This adds a component into the document that looks like the following:
You can allow the "Create" button to pre-populate a new document with a reference to the source document.
This feature can leverage the initialValue of a new document to set the reference. On the schema for the referencing document type, use the isIncomingReferenceCreation helper to check if an incoming reference field is creating the new document. Then pass in the reference to the appropriate field. In this example, the book document type references the author type.
import {defineType} from 'sanity'
import {isIncomingReferenceCreation} from 'sanity/structure'
export defineType({
name: "book",
fields: [
// ...
],
initialValue: (params) => {
return {
author: isIncomingReferenceCreation(params) ? params.reference : undefined,
}
},
)If you have existing documents that you want to search/assign to the current document, use the onLinkDocument option.
import {defineType} from 'sanity'
import {defineIncomingReferenceDecoration} from 'sanity/structure'
export default defineType({
name: 'author',
type: 'document',
renderMembers: (members) => {
return [
...members,
defineIncomingReferenceDecoration({
name: 'booksCreatedByThisAuthor',
options: {
types: [{type: 'book'}],
onLinkDocument: (document, reference) => {
return {
...document,
author: reference, // <-- the reference is passed to the document
}
},
},
}),
]
},
fields: [
defineField({type: "string", name: "name"}),
// ...
]
})You can also pass custom actions to the incoming reference field. This format is similar to document actions, but occurs in the defineIncomingReferenceDecoration helper. This example creates an action in ReferenceActions.tsx and applies it in the options.actions array.
import {defineType} from 'sanity'
import {defineIncomingReferenceDecoration} from 'sanity/structure'
import {RemoveReferenceAction} from './ReferenceActions'
export default defineType({
name: 'author',
type: 'document',
renderMembers: (members) => {
return [
...members,
defineIncomingReferenceDecoration({
name: 'incomingReferences',
title: 'Incoming references',
types: [{type: 'author'}],
actions: [RemoveReferenceAction]
}),
]
},
fields: [],
})import {type IncomingReferenceAction} from 'sanity/structure'
import {getDraftId} from 'sanity'
import {useState} from 'react'
export const RemoveReferenceAction: IncomingReferenceAction = ({document, getClient}) => {
const [dialogOpen, setDialogOpen] = useState(false)
const client = getClient({apiVersion: '2025-10-01'})
return {
label: 'Remove reference',
icon: TrashIcon,
tone: 'critical',
dialog: dialogOpen
? {
type: 'confirm',
message: 'Are you sure you want to remove the reference?',
onCancel: () => setDialogOpen(false),
onConfirm: async () =>
await client.createOrReplace({
...document,
_id: getDraftId(document._id),
author: undefined, // Removes the reference from the document
}),
}
: null,
onHandle: () => setDialogOpen(true),
}
}Cross-dataset references are also supported. You'll need to supply additional details as shown below.
import {defineType} from 'sanity'
import {defineIncomingReferenceDecoration} from 'sanity/structure'
export default defineType({
name: 'author',
type: 'document',
renderMembers: (members) => {
return [
...members,
defineIncomingReferenceDecoration({
name: 'incomingReferencesCrossDataset',
title: 'Incoming references CrossDataset',
types: [
{
type: 'book',
dataset: 'test-us',
title: 'Book in test-us dataset',
studioUrl: ({id, type}) => {
return type ? `/us/intent/edit/id=${id};type=${type}` : null
},
preview: {
select: {title: 'title', media: 'coverImage', subtitle: 'publicationYear'},
},
},
]
}),
]
},
fields: [],
