Sanity Tab Block Plugin

A Sanity Studio plugin that lets you create tabbed content blocks with customisable styles, layouts and rich text editing capabilities.

By Multidots

Install command

npm i @multidots/sanity-plugin-tab-block

@multidots/sanity-plugin-tab-block

A comprehensive tab block plugin for Sanity Studio that provides dynamic, customizable tab interfaces with rich content support.

🎯 Core Functionality

Multiple Tabs: Support for multiple tabs per block with validation
Rich Content: Portable Text support with headings, lists, links, and formatting
Flexible Layouts: Horizontal and vertical tab orientations with intelligent mobile adaptation
Responsive Design: Comprehensive responsive behavior across all device sizes
Full ARIA Compliance: Complete role, aria-selected, aria-controls, aria-labelledby, and tablist attributes

🎨 Customization Options

Layout Control: Choose between horizontal and vertical tab arrangements
Advanced Alignment Settings: Independent control over title, tab titles, content, and vertical alignment
Comprehensive Color Theming: Full color customization for all visual elements
- Block title color
- Tab title colors (active/inactive/hover states)
- Tab background colors (active/inactive states)
- Content text and background colors
- Tab hover colors

Installation

npm install @multidots/sanity-plugin-tab-block

1. Add the Plugin to Your Sanity Config

import {defineConfig} from 'sanity'
import {tabBlockPlugin} from '@multidots/sanity-plugin-tab-block'

export default defineConfig({
  // ... other config
  plugins: [
    tabBlockPlugin(),
    // ... other plugins
  ],
})

2. Add to Your Schema

// In your document schema
export default defineType({
  name: 'page',
  title: 'Page',
  type: 'document',
  fields: [
    defineField({
          name: "tabBlock",
          type: "tabBlock",
    }),
  ],
})

Update GROQ Queries to Include Tab Block

export const getPageQuery = defineQuery(`
  *[_type == 'page' && slug.current == $slug][0]{
    _id,
    _type,
    name,
    slug,
    tabBlock,
  }
}`);

Create a Component Wrapper

For a clean and maintainable frontend implementation, create a dedicated component wrapper first, then use it in your pages. This approach provides better code organization and reusability.

First, create a Tab.tsx component in your components directory:

  'use client'

import { TabBlock as TabBlockComponent, TabBlockData } from "@multidots/sanity-plugin-tab-block"
  import { PortableText } from 'next-sanity'

  type TabProps = {
      tab: TabBlockData
  }

  const Tab = ({ tab }: TabProps) => {
      return (
          <TabBlockComponent
              tab={tab}
              PortableText={(props: any) => <PortableText {...props} />}
          />
      )
  }

  export default Tab

Render in Your Page Example

Use in Your Page Component

import { TabBlockData } from '@multidots/sanity-plugin-tab-block';
import Tab from '@/components/Tab'

// Add code to get the page data

export default async function Page({ params }: RouteProps) {
    const { data: page } = await getPage(params);
    return  (
        <>
            {page?.tabBlock && (
                <Tab tab={page?.tabBlock as TabBlockData} />
            )}
        </>
    ) ;
}

Schema Fields

Field	Type	Description	Group
`title`	string	Optional title for the entire tab block	-
`tabs`	array	Array of tab objects (1-10 tabs)	Tabs & Content
`layout`	string	`'horizontal'` or `'vertical'`	Layout & Alignment
`titleAlignment`	string	`'left'`, `'center'`, or `'right'`	Layout & Alignment
`tabTitleAlignment`	string	`'left'`, `'center'`, or `'right'`	Layout & Alignment
`tabTitleVerticalAlignment`	string	`'start'`, `'center'`, or `'end'` (vertical layout only)	Layout & Alignment
`tabContentAlignment`	string	`'left'`, `'center'`, or `'right'`	Layout & Alignment

Color Customization

Color Field	Description	Usage
`titleColor`	Main block title color	Applied to the main title text
`tabTitleColor`	Inactive tab title color	Default color for tab buttons
`tabTitleHoverColor`	Tab title hover background color	Background color when hovering over tabs
`activeTabTitleColor`	Active tab title color	Text color for the currently active tab
`tabBackgroundColor`	Tab button background color	Default background for tab buttons
`activeTabBackgroundColor`	Active tab background color	Background color for the active tab
`tabContentColor`	Tab content text color	Text color within tab content areas
`tabContentBackgroundColor`	Tab content area background color	Background color for the content area

Tab Object Structure

Each tab in the tabs array contains:

{
  tabTitle: string        // Tab button text (required, 1-50 characters)
  content: PortableText[] // Rich text content (required)
}

Supported Rich Text Elements

Headings: H1, H2, H3, H4
Text Formatting: Bold, italic, underline
Lists: Bulleted and numbered lists
Blockquotes: Quote styling

Link Configuration

Links support:

HTTP/HTTPS URLs
Email addresses (mailto:)
Phone numbers (tel:)

TabBlock Component

interface TabBlockProps {
  tab: TabBlockData           // The tab block data from Sanity
  PortableText?: React.ComponentType<{value: unknown}>  // Portable Text renderer
  className?: string          // Additional CSS classes
}

TabBlockData Interface

interface TabBlockData {
  title?: string
  tabs?: Array<{
    tabTitle?: string
    content?: unknown[]
    _type?: string
    _key?: string
  }>
  layout?: 'horizontal' | 'vertical'
  titleAlignment?: 'left' | 'center' | 'right'
  tabTitleAlignment?: 'left' | 'center' | 'right'
  tabTitleVerticalAlignment?: 'start' | 'center' | 'end'
  tabContentAlignment?: 'left' | 'center' | 'right'
  // Color properties
  titleColor?: {hex: string}
  tabTitleColor?: {hex: string}
  tabTitleHoverColor?: {hex: string}
  activeTabTitleColor?: {hex: string}
  tabBackgroundColor?: {hex: string}
  activeTabBackgroundColor?: {hex: string}
  tabContentColor?: {hex: string}
  tabContentBackgroundColor?: {hex: string}
}

Responsive Design

The component automatically adapts to different screen sizes:

Desktop & Tablet: Maintains chosen layout (horizontal/vertical)
Mobile: Vertical tabs convert to horizontal scrollable navigation

Custom Styling

You can override styles by:

Passing a className prop to the component
Using CSS specificity to override built-in styles
Customizing colors through the Sanity interface
Targeting specific responsive breakpoints

CSS Classes

The component generates these CSS classes:

.tab-block - Main container
.tab-block-title - Block title
.tab-container - Tab layout container (.horizontal or .vertical)
.tab-nav - Tab navigation container
.tab-nav-item - Individual tab buttons (.active for current tab)
.tab-content - Content area
.tab-panel - Individual content panels (.hidden for inactive panels)

Backend Settings:

https://share.cleanshot.com/vyGd88Rybns7g2vwmxZW

Frontend Horizontal View:

https://share.cleanshot.com/3x4DB3JYSZCFyhBR8MK0

Frontend Vertical View:

https://share.cleanshot.com/0Q5yBP3KTlszMFMST5Ft

Testing in Sanity Studio

See Testing a plugin in Sanity Studio for instructions on how to run this plugin with hotreload in your studio.

Advanced Configuration

// Full customization with all available options
{
  _type: 'tabBlock',
  title: 'Service Information',
  layout: 'vertical',
  titleAlignment: 'center',
  tabTitleAlignment: 'left',
  tabTitleVerticalAlignment: 'start',
  tabContentAlignment: 'left',
  titleColor: {hex: '#2D3748'},
  tabTitleColor: {hex: '#4A5568'},
  tabTitleHoverColor: {hex: '#F7FAFC'},
  activeTabTitleColor: {hex: '#3182CE'},
  tabBackgroundColor: {hex: 'transparent'},
  activeTabBackgroundColor: {hex: '#EBF8FF'},
  tabContentColor: {hex: '#2D3748'},
  tabContentBackgroundColor: {hex: '#F7FAFC'},
  tabs: [
    {
      tabTitle: 'Overview',
      content: [
        {
          _type: 'block',
          children: [{text: 'Comprehensive service overview...'}]
        }
      ]
    },
    {
      tabTitle: 'Features',
      content: [
        {
          _type: 'block',
          children: [{text: 'Key features and benefits...'}]
        }
      ]
    }
  ]
}

Common Issues

Issue: Tabs not rendering properly

Solution: Ensure you're passing the PortableText component prop

Issue: Styles not applying

Solution: Check that color values are in the correct {hex: string} format

Issue: Content not displaying

Solution: Verify that tab content is properly structured Portable Text

Performance Tips

Tab Limits: Keep tabs to 10 or fewer for optimal performance and user experience
Content Optimization: Use lazy loading for heavy content in tabs
Mobile Considerations: Consider tab content length and title length for mobile users
Color Usage: Use the built-in color customization rather than custom CSS for better performance
Responsive Testing: Test on various devices to ensure optimal responsive behavior
