sanity-plugin-arena-sync

Sanity Studio v3 plugin for managing Are.na channel sync — channel picker, block browser, structure builder, and bundled schemas.

Features

• Channel picker — browse all your Are.na channels in a searchable, filterable grid; toggle sync per channel
• Block browser — search, filter, and preview synced blocks without leaving the plugin tool
• Structure builder — organized desk hierarchy: All Blocks, By Type, By Channel, Orphans, Sync Config, Channel Settings
• Bundled schemas — areNaBlock, arenaSyncConfig, arenaChannelSettings auto-registered by the plugin
• Extensible schemas — disable auto-registration and spread/extend with your own fields
• Real-time updates — listens for arenaSyncConfig changes via Sanity listener
• Manual sync trigger — POST to your backend endpoint from the UI

This plugin is part of the arena-sanity-sync ecosystem.

Installation

npm install sanity-plugin-arena-sync

Quick start (zero config)

import { defineConfig } from "sanity";
import { structureTool } from "sanity/structure";
import { arenaSyncPlugin, arenaStructure } from "sanity-plugin-arena-sync";

export default defineConfig({
  // ...
  plugins: [
    structureTool({ structure: arenaStructure }),
    arenaSyncPlugin(),
  ],
});

This auto-registers all three schemas and gives you the full desk structure. Done.

Configuration

Are.na access token (required for channel picker)

The plugin needs your Are.na API token to fetch your channels. Provide it in one of two ways:

Option A: Environment variable (recommended)

SANITY_STUDIO_ARENA_ACCESS_TOKEN=your_arena_token

Vite auto-exposes SANITY_STUDIO_* vars via import.meta.env.

Option B: Plugin config

arenaSyncPlugin({ arenaAccessToken: "your_arena_token" });

Sync endpoint (optional)

To enable the "Trigger Sync" button, configure the URL the plugin will POST to.

Via Sanity document: set the syncEndpoint field on the arenaSyncConfig document.

Via environment variable:

SANITY_STUDIO_SYNC_ENDPOINT=https://your-app.xyz/api/sync

Schemas

The plugin bundles three document schemas:

By default, arenaSyncPlugin() auto-registers all three. No manual schema.types needed.

Extending schemas with custom fields

The whole point of syncing to Sanity is adding your own fields. To extend a schema, disable auto-registration and spread the base:

import { defineConfig, defineField } from "sanity";
import { structureTool } from "sanity/structure";
import { colorInput } from "@sanity/color-input";
import {
  arenaSyncPlugin,
  arenaStructure,
  arenaBlockSchema,
  arenaSyncConfigSchema,
  arenaChannelSettingsSchema,
} from "sanity-plugin-arena-sync";

export default defineConfig({
  plugins: [
    structureTool({ structure: arenaStructure }),
    colorInput(),
    arenaSyncPlugin({ schemas: false }), // disable auto-registration
  ],
  schema: {
    types: [
      // Pass through unchanged
      arenaBlockSchema,
      arenaSyncConfigSchema,

      // Extend channel settings with a color field
      {
        ...arenaChannelSettingsSchema,
        fields: [
          ...arenaChannelSettingsSchema.fields,
          defineField({
            name: "channelColor",
            title: "Channel Color",
            type: "color",
            options: { disableAlpha: true },
          }),
        ],
      },
    ],
  },
});

The same pattern works for adding fields to arenaBlockSchema — e.g. a featured boolean, a category reference, or any custom field your frontend needs.

Structure builder

The plugin exports two structure helpers:

arenaStructure(S, ctx)

Complete structure resolver. Drop it into structureTool() for the full hierarchy:

Content
├── Are.na
│   ├── All Blocks
│   ├── By Type
│   │   ├── Images
│   │   ├── Text
│   │   ├── Links
│   │   ├── Attachments
│   │   └── Media
│   ├── By Channel          (dynamic — fetched from data)
│   │   ├── channel-slug-1
│   │   └── channel-slug-2
│   ├── Orphans              (isOrphan == true)
│   ├── ──────
│   ├── Sync Config          (singleton editor)
│   └── Channel Settings     (per-channel, auto-listed from config)
├── ──────
└── (other document types)

structureTool({ structure: arenaStructure });

arenaStructureItem(S, ctx)

Just the Are.na list item — compose it with your own structure:

structureTool({
  structure: (S, ctx) =>
    S.list()
      .title("Content")
      .items([
        arenaStructureItem(S, ctx),
        S.divider(),
        // ...your other items
      ]),
});

Block browser

The "Browse Blocks" tab in the plugin tool lets you search and filter synced blocks from Sanity:

• Search — debounced title search
• Type filter — All / Image / Text / Link / Attachment / Media
• Channel filter — dropdown populated from your data
• Grid view — responsive card grid with thumbnails
• Preview dialog — click a card to see full details, "Open in Editor" intent link, "View on Are.na" external link
• Pagination — "Load More" button

Exports

// Plugin
export { arenaSyncPlugin };

// Structure
export { arenaStructure, arenaStructureItem };

// Schemas (for extending)
export { arenaBlockSchema, arenaSyncConfigSchema, arenaChannelSettingsSchema };

// All schemas as an array
export { arenaSchemas };

Plugin options

How it works

1. On mount, the plugin calls GET /v3/me with your token to resolve your Are.na user
2. Paginates GET /v3/users/{slug}/contents?type=Channel to load all channels
3. Fetches arenaSyncConfig from Sanity to determine which channels are selected
4. Toggling a channel card immediately patches channelSlugs in the config doc (optimistic UI)
5. If the config doc doesn't exist yet, it's created on first toggle

Sync endpoint requirements

Your endpoint should:

1. Accept POST requests
2. Call syncArenaChannels() from arena-sanity-core
3. Return JSON with success: boolean (or overallSuccess: boolean)

Example: see arena-sanity-adapter-nuxt.

Development

pnpm build    # Build
pnpm lint     # Lint
pnpm watch    # Watch mode

Dev studio at studio/ in the monorepo root:

cd studio && pnpm dev

Related packages

• arena-sanity-core — sync engine & CLI
• arena-sanity-adapter-nuxt — Nuxt 3 API route

License

MIT - Bartek Pierscinski
